Engineering Wheel Rim 25-22.00/3.0-3PCS for Loader OTR Tyre 26.5-25

Quantity:
Availability:





Inquire Add to Basket

Model:
25-22.00/3.0-3PCS
Brand:
RICHRISE

Product Description

Products Description

Custom Wheels: Wholesale, Retail, Brand Customization

Based on the parameters you provide, we can create detailed production blueprints and custom - make wheels.

Our product is available for wholesale and retail.

For large - scale orders, we offer brand and packaging customization. This enables you to build a unique product image that suits your business needs.

★★★ If you're unsure about the required product parameters, refer to the product measurement method at the end of the page to accurately determine the details for your order.

size	matching tires	tire type	disc type	offset /mm	assembly height /mm	center hole /mm	bolt hole D.I.A	bolt hole	P.C.D /mm
25-22.00/3.0-3PCS	26.5-25	inner tube	plate	77.5	371	φ448	φ24	19	φ500
25-22.00/3.0-3PCS	26.5-25	inner tube	plate	8	285.5	φ468	φ24	16	φ520
25-22.00/3.0-3PCS	26.5-25	inner tube	plate	8	285.5	φ468	φ24	16	φ520
25-22.00/3.0-3PCS	26.5-25	inner tube	plate	45	250	φ446	φ24	12	φ500
25-22.00/3.0-3PCS	26.5-25	inner tube	plate	21	272.9	φ295	φ26	22	φ345
25-22.00/3.0-3PCS	26.5-25	inner tube	plate	77.5	371	φ448	φ24	19	φ500
25-22.00/3.0-3PCS	26.5-25	inner tube	plate	17	276	φ458	φ23	19	φ510
25-22.00/3.0-3PCS	26.5-25	inner tube	plate	22.5	316	φ448	φ24	19	φ500
25-22.00/3.0-3PCS	26.5-25	inner tube	plate	10	301	φ455	φ21.5	20	φ510
25-22.00/3.0-3PCS	26.5-25	inner tube	plate	52.5	346	φ448	φ24	19	φ500
25-22.00/3.0-3PCS	26.5-25	inner tube	plate	8	302.4	φ458	φ24	19	φ510
25-22.00/3.0-3PCS	26.5-25	inner tube	plate	45	250	φ446	φ24	20	φ500
25-22.00/3.0-3PCS	26.5-25	inner tube	plate	20	275.4	φ446	φ24	12	φ500
25-22.00/3.0-3PCS	26.5-25	inner tube	plate	-8	285.4	φ468	φ24	16	φ520
25-22.00/3.0-3PCS	26.5-25	inner tube	plate	8	285.5	φ468	φ24	16	φ520
25-22.00/3.0-3PCS	26.5-25	inner tube	plate	8	285.5	φ474	φ24	16	φ520
25-22.00/3.0-3PCS	26.5-25	inner tube	plate	8	285.5	φ468	φ24	16	φ520
25-22.00/3.0-3PCS	26.5-25	inner tube	plate	-50	343.4	φ446	φ24	12	φ500
25-22.00/3.0-3PCS	26.5-25	inner tube	plate	8	285.5	φ468	φ24	16	φ520
25-22.00/3.0-3PCS	26.5-25	inner tube	plate	-50	343.4	φ446	φ24	19	φ500
25-22.00/3.0-3PCS	26.5-25	inner tube	plate	20	273.4	φ446	φ24	19	φ500
25-22.00/3.0-3PCS	26.5-25	inner tube	plate	50	243.4	φ458	φ24	19	φ510
25-22.00/3.0-3PCS	26.5-25	inner tube	plate	20	273.4	φ458	φ24	19	φ510
25-22.00/3.0-3PCS	26.5-25	tubeless	plate	5	127.4
25-22.00/3.0-3PCS	26.5-25	tubeless	plate	55	77.8
25-22.00/3.0-3PCS	26.5-25	tubeless	plate	21	273	φ295	φ26	22	φ345
25-22.00/3.0-3PCS	26.5-25	tubeless	plate	45	247.4	φ446	φ24	12	φ500
25-22.00/3.0-3PCS	26.5-25	tubeless	plate	10	303.4	φ455	φ21.5	20	φ510
25-22.00/3.0-3PCS	26.5-25	tubeless	plate	30	264.2	φ448	φ24	19	φ500
25-22.00/3.0-3PCS	26.5R25	tubeless	plate	8	285.5	φ468	φ24	16	φ520

MEASURING METHOD

图纸说明-三件式17.00-25 10-30 285 230_01

If you can't figure out which wheel is your ideal match? No sweat! Our team is fully dedicated to customized production using thes amples you send over. Just pack up those samples and mail them right over to us, and let's get started on creating the perfect wheel tailored just for you.
