W10x24 Agricultural Tractor Wheel Rim -Compatible with 11.2-24 Tractor Tires

Wheel Size:W10x24
Product name:tractor/agricultural wheel rim
Assembled Tire Size:11.2-24
Material:Steel 380CL/400CL
Type:tractor accessories,agriculture accessories
BRAND:LANDCROWN ,RICHRISE
OEM:Support
Certification:1S09001/TS16949,INMETRO, EAC
MOQ :50PCS
Replacement wheel rims for tractor/agricultural machinery :John Deere,Case IH,New Holland, Massey Ferguson,CLAAS,Kubota,Mahindra,Yanmar, Deutz-Fahr,Valtra,Fendt and other global brands.
Color Options: Silver/white/yellow/green/blue etc. (can be customized)
Quality Guarantee:3 Year
Place of Origin: Shandong, China (Mainland)

Quantity:
Availability:





Inquire Add to Basket

Model:
W10x24
Brand:
RICHRISE

W10x24 AGRICULTURAL WHEEL RIM SPECIFICATIONS

农机轮-模板

WHEEL SIZE	CONNECTION TYPE	BOLT HOLE	BOLT HOLE DIA	PCD	CB	ET
W10X24	bolted connection	8	φ17	φ330	φ290.5	48
W10X24	bolted connection	8	φ17	φ330	φ290.5	31
W10X24	bolted connection	6	φ17	φ165	φ130	5.5
W10X24	bolted connection	6	φ17	φ165	φ130	14.5
W10X24	bolted connection	8	φ17	φ330	φ290.5	51
W10X24	bolted connection	6	φ17	φ165	φ130	55.5
W10X24	bolted connection	6	φ17	φ165	φ130	43.5
W10X24	bolted connection	8	φ22	φ275	φ221	51
W10X24	bolted connection	8	φ17	φ330	φ290	51
W10X24	bolted connection	8	φ19	φ203.2	φ152.6	5
W10X24	bolted connection	8	φ17	φ203.2	φ152.4	42
W10X24	bolted connection	8	φ17	φ330	φ290.5	81
W10X24	bolted connection	6	φ17	φ180	φ141	82
W10X24	bolted connection	8	φ17	φ330	φ290.5	81.5
W10X24	bolted connection	8	φ19	φ203.2	φ152.6	87
W10X24	bolted connection	6	φ17	φ165	φ130	120
W10X24	bolted connection	8	φ17	φ330	φ290	51
W10X24	bolted connection	8	φ19	φ203.2	φ152.4	50
W10X24	bolted connection	6	φ17	φ161	φ100	18
W10X24	bolted connection	6	φ17	φ165	φ130	31.5
W10X24	bolted connection	8	φ19	φ203.2	φ152.4	70
W10X24	bolted connection	10	φ19	φ310	φ260.2	16
W10X24	bolted connection	6	φ17	φ165	φ130	55.5
W10X24	bolted connection	8	φ20	φ190	φ145	150
W10X24	bolted connection	8	φ17	φ330	φ290.5	44
W10X24	bolted connection	8	φ17	φ203.2	φ152.4	42
W10X24	bolted connection	6	φ17	φ165	φ130
W10X24	bolted connection	8	φ21	φ275	φ221	67
W10X24	bolted connection	8	φ17	φ330	φ290.5	81
W10X24	bolted connection	6	φ17	φ165	130.2	111
W10X24	bolted connection	8	φ17	φ330	φ290.5	13
W10X24	bolted connection	6	φ17	φ165	130.2	25
W10X24	bolted connection	6	φ17	285	250.5	50
W10X24	bolted connection	6	φ17	φ165	φ130	96.5
W10X24	bolted connection	8	φ17	φ330	φ290	60
W10X24	bolted connection	8	φ19	φ275	φ221	0
W10X24	bolted connection	6	φ17	φ165	φ130	4
W10X24	bolted connection	8	φ20	φ190	φ145	1
W10X24	bolted connection	6	φ15	φ161	φ102	-34
W10X24	bolted connection	6	φ17	φ180	φ141	50
W10X24	bolted connection	8	φ16.5	φ330	φ290	82
W10X24	bolted connection	8	φ19	φ203.2	φ152.4	86
W10X24	bolted connection	8	φ21.5	φ330	φ221	70
W10X24	bolted connection	6	φ17	φ165	φ130	-44.5
W10X24	bolted connection	8	φ19	φ203.2	φ152.4	20
W10X24	bolted connection	8	φ17	φ330	φ290	81.5
W10X24	bolted connection	6	φ17	φ165	φ130	4
W10X24	bolted connection	8	φ17	φ203.2	φ152.4	51
W10X24	bolted connection	8	φ22	φ275	φ221	51
W10X24	bolted connection	8	φ17	φ330	φ290.5	-89
W10X24	bolted connection	8	φ19	φ203.2	φ152.4	16
W10X24	bolted connection	8	φ19	φ203.2	φ152.4	39.3
W10X24	bolted connection	6	φ17	φ165	φ130	59.5
W10X24	bolted connection	8	φ18	φ330	φ290	36
W10X24	bolted connection	8	φ19	φ203.2	φ152.4	51
W10X24	bolted connection	8	φ17	φ330	φ290.5	85
W10X24	bolted connection	6	φ17	φ180	φ141	50
W10X24	bolted connection	6	φ15	φ152	φ118	51
W10X24	bolted connection	8	φ18	φ330	φ290	36
W10X24	bolted connection	8	φ17	φ330	φ290.5	81
W10X24	bolted connection	6	φ15	φ161	φ102	50
W10X24	bolted connection	6	φ17	φ165	φ130	0
W10X24	welding flange	8	φ17	φ330	φ290.5	81
W10X24	welding flange	8	φ17	φ203.2	φ152.4
W10X24	welding flange	8	φ19	φ203.2	φ152.4
W10X24	welding flange	10	φ19	φ310	φ260.2	16
W10X24	welding flange	10	φ19	φ310	φ260.2	24
W10X24	welding flange	8	φ17	φ330	φ290.5	145
W10X24	welding flange	8	φ23	φ210	φ140	135
W10X24	welding flange	8	φ19	φ203.2	φ152.4	200
W10X24	welding flange	8	φ19	φ203.2	φ152.4	151
